Acrel AIM-T300 Insulation Monitoring Device Monitor The Insulation Condition Of Low Voltage IT Distribution System

Brand Name : Acrel

Model Number : AIM-T300

Certification : CE

Place of Origin : China

MOQ : 1pc

Payment Terms : T/T

Supply Ability : 5000pc/day

Delivery Time : 5-8 work days

Packaging Details : carton

Accessory power supply : AC 85~265V; DC100~300V

System application : IT system (online), Other system (offline)

Alarm type : LCD, LED indicator

Communication : RS485 Modbus RTU

System voltage : AC 0~480V; DC 0~480V; 40~460Hz

Contact Now

AIM-T300 insulation monitoring device

AIM-T300 insulation monitoring device is designed and developed by Acrel gathering the design experience of electric power meter industry for many years to monitor the insulation condition of low voltage IT distribution system (ungrounded system). The product adopts advanced micro controller technology, with high degree of integration, compact size and easy installation, and it integrates intelligence, digitalization and networking. The device, with many functions such as insulation fault warning, fault alarm, event recording and so on, can be used in the mines, glass factories, electric furnaces and test facilities, metallurgical plants, chemical plants, and exploded dangerous places, computer center, emergency power supply and other places to monitor the insulation status of IT system in real time. When insulation fault occurs, it will alarm and remind the staff to check the fault.
The products conform to the requirements of enterprise standard Q/VDCL-26-2017 IT System Insulation Monitor.

Acrel AIM-T300 Insulation Monitoring Device Monitor The Insulation Condition Of Low Voltage IT Distribution SystemAcrel AIM-T300 Insulation Monitoring Device Monitor The Insulation Condition Of Low Voltage IT Distribution SystemAcrel AIM-T300 Insulation Monitoring Device Monitor The Insulation Condition Of Low Voltage IT Distribution System

Technical parameters

Item AIM-T300
Power supply AC85~265V
Power consumption <8W
System voltage AC0~480V, DC0~480V
Rated frequency 40~60Hz
Insulation
monitoring		 Measuring range 1k~5MΩ
Alarm range 10k~5MΩ
Response time(Ce=1uF) <6s
System leakage capacitance <150uF
Internal
parameters		 Measuring voltage <20V
Measuring current <170uA
Internal DC impedance ≥120kΩ
Relay output Warning, Alarm
Communication RS485.Modbus-RTU
Environment Working temperature -20~+60℃
Storage temperature -20~+70℃
Relative humidity 5%-95%,without condensation
Altitude ≤2500m

Acrel AIM-T300 Insulation Monitoring Device Monitor The Insulation Condition Of Low Voltage IT Distribution SystemAcrel AIM-T300 Insulation Monitoring Device Monitor The Insulation Condition Of Low Voltage IT Distribution SystemAcrel AIM-T300 Insulation Monitoring Device Monitor The Insulation Condition Of Low Voltage IT Distribution System
