Acrel AGF-M20T Monitoring The Running State Of Solar Panels Solar PV String Monitor Meter Base Electricity Device RS485

Name: Acrel AGFM20T Monitoring The Running State Of Solar Panels Solar PV String Monitor Meter Base Electricity Device RS485
Brand: Acrel
Price: 1 USD

Brand Name : Acrel

Model Number : AGF-M20T

Certification : CE

Place of Origin : China

MOQ : 1pc

Payment Terms : T/T

Supply Ability : 5000pc/day

Delivery Time : 5-8 work days

Packaging Details : carton

Product name : String monitoring meter

Rated voltage : 1500VDC

Communication : RS485

Application : Solar Panel

Max current : 20A

Contact Now

Multi circuit solar string energy meter

AGF-T Perforation type PV confluence acquisition device is specially designed for smart PV combiner box. It is used for monitoring the running state of solar panels in solar cell arrays, measuring the currents of solar cell, detecting the state of surge protection devices and DC breaker. The device is equipped with RS485(Modbus) communication port for transmitting all the datas to master device.

Acrel AGF-M20T Monitoring The Running State Of Solar Panels Solar PV String Monitor Meter Base Electricity Device RS485

Company

Acrel AGF-M20T Monitoring The Running State Of Solar Panels Solar PV String Monitor Meter Base Electricity Device RS485

Product Tags:

Acrel AGF-M20T Monitoring The Running State Of Solar Panels Solar PV String Monitor Meter Base Electricity Device RS485 Images
